Z-20GW1
![Z-20GW1]()
Z-20GW1
Available: Out of Stock
- Product SKU: Z-20GW1
- Category:Electromechanical Switches
- Contact for high volume orders (25 or more) for special pricing
$30.67 CAD
| Model: | Z-20GW1 |
| Operating Speed: | 0.01mm-1m/sec |
| Operating Frequency: | Mechanical: 240 ops/min Electrical: 20 ops/min |
| Insulation Resistance: | >100MΩ@500V |
| Rated Voltage/Current: |
20A,125/250/480VAC,1.5HP/125VAC or 2HP/250VAC |
| Service Life: | Mechanically 1×107 (Operations) Electrically 5×105 (Operations) |
| Operating Temperature: | About -25~+80 (-4~+176) |
| Humidity: | <95%RH |
| Degree of protection: | IP00/IP63 |
| Delectric Strength: | 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts |
