MSDXLM350

Available: 20 items in stock
  • MSD Connector with 350A Fuse
  • Integrated internal HVIL for additional safety
  • Unique cooling structure for optimum performance
  • High current contacts with Amphenol Radsok technology
  • Tool-free disconnection for easy maintenance
  • Flexible mounting options: front or rear
$309.85 CAD

MSD Connectors

Excel|Mate MSD XL is a high-quality solution for the maintenance of hybrid electric vehicles (HEV) and offers safe disconnection of the high-voltage contacts thanks to a two-stage lever for opening the HVIL circuit (High Voltage Interlock Loop). The high-voltage contact surfaces are designed to be safe to touch.

Datasheet (PDF)
Drawing (PDF)

MSD Connectors

Excel|Mate MSD XL is a high-quality solution for the maintenance of hybrid electric vehicles (HEV) and offers safe disconnection of the high-voltage contacts thanks to a two-stage lever for opening the HVIL circuit (High Voltage Interlock Loop). The high-voltage contact surfaces are designed to be safe to touch.

Datasheet (PDF)
Drawing (PDF)

Model: MSDXLM350
Current Rating: 350A
Rated Voltage: 1000V DC
Product Category: Automotive Connectors
Gender:  Plug (Male)
Mounting Style:  Panel Mount
Series:  MSD XL
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
Product Type: Automotive Connectors
Protection Degree: IP67, IP6K9K (mated)
