HVSL1400022C1H8
Available: 10 items in stock
- HVSL 1400 2 Ways Receptacle
- C-coded
- Straight Threas
- HVIL
- Product SKU: HVSL1400022C1H8
- Category:EV Connectors
- Contact for high volume orders (25 or more) for special pricing
$135.78 CAD
High Voltage Safety Lock (HVSL) Connectors
The new high power connectors Excel|Mate HVSL 1400 are built for various EV applications. The protection class of IP67 / IP6K9K / IP2XB guarantees a secure connection under harsh environmental conditions. HVSL 1400 is offering a design for wire gauges from 70 up to 120 mm², current carrying capacity up to 430 A and 1000V DC.
High Voltage Safety Lock (HVSL) Connectors
The new high power connectors Excel|Mate HVSL 1400 are built for various EV applications. The protection class of IP67 / IP6K9K / IP2XB guarantees a secure connection under harsh environmental conditions. HVSL 1400 is offering a design for wire gauges from 70 up to 120 mm², current carrying capacity up to 430 A and 1000V DC.
| Model: | HVSL1400022C1H8 |
| Number of Positions (w/o PE) | 2 |
| Rated Voltage: | 1000V |
| Rated Current: | 450A |
| IP-Class Mated: | IP67 / IP6K9K |
| Gender: | Male Receptacle |
| Termination Style: | Other |
| High Voltage Interlock | Yes |
| Maximum Operating Temperature: | + 70 C |
| Minimum Operating Temperature: | - 40 C |
| Product Type: | Automotive Connectors |
| Shielding: | Yes |
| RoHS Compliant: | Yes |
