QML-250-D-24
![QML-250-D-24]()
![QML-250-D-24]()
QML-250-D-24
Available: 3 items in stock
- Excellent oil resistance with a special sealing structure with IP67 protection rating, suitable for machine tool applications with cutting fluids
- Suitable for high pressure and high temperature water cleaning environments(IP69K)
- Tempered glass prevents damage from machine tool chips
- Foreign substances do not accumulate on the shielding glass surface of the working light due to its flush structure to the housing structure oft he product
- Can select from a variety of bracket options from direct mount, tilt mount, and pan/ tilt mount type to fit your work environment or lighting condition needs
- Equipped anti-glare filter
- Suitable for environments that require stable intensity illumination for improved visibility
- Standard entry cable included. Can customize the product with the M12 connector if requested
- Customized oil resistant cable attached type available
- Product SKU: QML-250-D-24
- Category:Flashers & Sounders
- Contact for high volume orders (25 or more) for special pricing
$304.21 CAD
QML Series
Water, vibration and oil resistant LED work light, suitable for machine tools applications and high temperature water cleaning environments.
QML Series
Water, vibration and oil resistant LED work light, suitable for machine tools applications and high temperature water cleaning environments.
| Model: |
QML-250-D-24 |
| Lens Color: |
Translucent |
| Light Color (Standard): |
Cooldaylight |
| Color Temperature (Standard): |
6,000~7,000K |
| Luminous Flux: |
2,014lm |
| Illumination (at 1m): | 890Lux |
| Product Feature: | Illumination (at 1m): 890Lux |
| Rated Voltage: | DC24V |
| Range for Operation Voltage: | DC21.5V~26.5V |
| Power Consumption: | 30W |
| Insulation Resistance: | Min. 100MΩ(500V DC mega ohm meter) |
| Withstanding Voltage: | DC:500V AC, 60Hz, 1minute |
| Operating Temperature: | -30℃~+60℃ |
| Waterproof: | IP67 / IP69K |
| Materials: | Housing: AL Lens: Tempered glass |
| Certificates: | CE, UL |
| Weight (approx.): | 1.30kg |
